ROE-C Series

Features :

To meet the use requirements of encoder for CNC industry, Delta has launched a new encoder product specialized for CNC Machine Tool– CS7 series. For the solution of high resonance and much oil & gas problem occurred in machine tool application, CS7 series not only have the new mechanical design, but also provide high standard electric specifications. The corresponding rotation speed of CS7 series can achieve 8000rpm, and the response frequency of output signal can also reach 300kHZ. This new series product can satisfy the needs of all kinds of CNC machine tools.

Specifications :

• CS Series: Outer Diameter of Solid Shaft: 70mm
• Resolution: 1024ppr
• Output Form: Line Driver
• Power Voltage Range: 7-24V
• Responsiveness: 300kHz max.
• IP degree: IP55 & 70°C

Applications :

CNC Machine Tool
